The Cat 395 Excavator is a powerhouse that gets the job done every time. Built with the 540 horsepower Cat C18 engine, this machine is a groundbreaking rockstar with fast cycle times and a powerful digging force that eases bucket penetration and digs down deep with maximum digging depths from 7.2 m (23.7 ft) up to 11.7m (38.5 ft).
Equipped with the latest Cat technology, the 395 helps you make informed and smart decisions to help improve jobsite efficiency, increase productivity, and return safely home every day. If you want to generate big-time results for your business, put the 395 next generation excavator to work. It is the top choice in its size class.
| Model | 395 |
| Net Power | 404 kW |
| Net Power - ISO 9249 (DIN) | 550 hp (metric) |
| Engine Model | Cat C18 |
| Engine Power - ISO 14396 | 405 kW |
| Net Power - ISO 9249 (DIN) | 551 hp (metric) |
| Bore | 145 mm |
| Stroke | 183 mm |
| Displacement | 18.1 L |
| Operating Weight | 94100 kg |
| Max Digging Depth | 7190 mm |
| Boom | Mass 7.25 m (23'9") |
| Stick | Mass 2.92 m (9'7") |
| Bucket | SDV 6.5 m³ (8.5 yd³) |
| Maximum Reach at Ground Level | 12260 mm |
| Maximum Cutting Height | 12370 mm |
| Maximum Loading Height | 7960 mm |
| Minimum Loading Height | 3660 mm |
| Maximum Depth Cut for 2440 mm (8 ft) Level Bottom | 7050 mm |
| Maximum Vertical Wall Digging Depth | 458 mm |
| Bucket Digging Force - ISO | 497 kN |
| Stick Digging Force - ISO | 394 kN |
